Xpelair XIMX150 Inline Mixed Flow Duct Fan 93083AW 6" - 150mm
Suggested products
Free 14 day returns
Changed your mind or ordered the wrong unit? You have 14 days from delivery to send it back. As long as items are unused and in their original packaging, we'll arrange your refund. Just contact our team and we'll take care of the rest. Made-to-order and bespoke items are non-returnable.
Why choose eFans?
- Bulk pricing available
- Free help and advice
- Fast quotes, usually within the hour
- Huge range with next-day delivery
- Credit accounts available
Delivery and Warranty
Standard UK Mainland Delivery
If you are not in a rush, then we offer standard delivery and your order should be with you between 2-3 working days.
£6.95
Next Working Day Delivery
Place your order before 12pm Monday to Thursday and receive your order the next working day. Orders placed on Friday before 11am will be processed and delivered on Monday. (Excludes Sunday’s and Public Holidays)
£15.95
Nominated Day Delivery
We know sometimes you will need an order on a particular date in the future. Simply select this option at checkout and add what date you would like to receive the order. We will then contact you to confirm the date. If you need to change this order date then please contact us ASAP.
£15.95
Northern Ireland Delivery
We offer a flat fee rate for Northern Ireland orders, and all are 5-7 working day lead times.
£29.95
Scottish Highlands & Islands Delivery
We only offer a flat fee rate for Scottish Highland & Islands orders, and all are 5-7 working day lead times.
£45.95
Channel Islands Delivery
We only offer a flat fee rate for Channel Islands orders, and all are 5-7 working day lead times.
£45.95
Product Details
Specifications
Product specifications
| Brand | Xpelair |
| Model | XIMX150 |
| Type | In-line mixed-flow duct fan |
| Duct connection | 150 mm |
| Airflow (max) | 520 m³/h |
| Motor | 2-speed AC, lubricated-for-life, maintenance-free (230 V, 50/60 Hz) |
| Power | 30/60 W |
| Timer | No |
| Rating | IPX4; Part F compliant; thermal cut-out |
| Warranty | 2 Year Manufacturer |
Summary
See more specification See less specification
The Xpelair XIMX150 is a 150 mm in-line mixed-flow extract fan offering strong duties for a wide range of ducted applications. Its centrifugal impeller improves airflow, it's Part F compliant for bathroom installation, and it moves up to 520 m³/h.
- Airflow up to 520 m³/h; 150 mm connection
- Two-speed AC motor; lubricated-for-life and maintenance-free, with thermal cut-out protection
- Centrifugal impeller for improved airflow
- Power 30/60 W; IPX4 rated; Part F compliant
- Convenient mounting cradle and easily accessible terminal box
Suitable for
- Inline loft fitting; bathrooms, conservatories, living rooms, offices and warehouses
- Domestic and light-commercial duct systems
Installation
Includes a mounting cradle that simplifies installation and inspection, with an easily accessible terminal box. Should be installed on a suitable circuit by a qualified electrician.
Specifications
| Brand | Xpelair |
| Model | XIMX150 |
| Type | In-line mixed-flow duct fan |
| Duct connection | 150 mm |
| Airflow (max) | 520 m³/h |
| Motor | 2-speed AC, lubricated-for-life, maintenance-free (230 V, 50/60 Hz) |
| Power | 30/60 W |
| Timer | No |
| Rating | IPX4; Part F compliant; thermal cut-out |
| Warranty | 2 Year Manufacturer |
Manuals & Guides
Xpelair XIMX150 Datasheet
Xpelair XIMX150 Installation Manual
Product Description
The Xpelair XIMX150 is a 150 mm in-line mixed-flow extract fan offering strong duties for a wide range of ducted applications. Its centrifugal impeller improves airflow, it's Part F compliant for bathroom installation, and it moves up to 520 m³/h.
- Airflow up to 520 m³/h; 150 mm connection
- Two-speed AC motor; lubricated-for-life and maintenance-free, with thermal cut-out protection
- Centrifugal impeller for improved airflow
- Power 30/60 W; IPX4 rated; Part F compliant
- Convenient mounting cradle and easily accessible terminal box
Suitable for
- Inline loft fitting; bathrooms, conservatories, living rooms, offices and warehouses
- Domestic and light-commercial duct systems
Installation
Includes a mounting cradle that simplifies installation and inspection, with an easily accessible terminal box. Should be installed on a suitable circuit by a qualified electrician.
Specifications
| Brand | Xpelair |
| Model | XIMX150 |
| Type | In-line mixed-flow duct fan |
| Duct connection | 150 mm |
| Airflow (max) | 520 m³/h |
| Motor | 2-speed AC, lubricated-for-life, maintenance-free (230 V, 50/60 Hz) |
| Power | 30/60 W |
| Timer | No |
| Rating | IPX4; Part F compliant; thermal cut-out |
| Warranty | 2 Year Manufacturer |
Manuals & Guides
Xpelair XIMX150 Datasheet
Xpelair XIMX150 Installation Manual
Delivery & Returns
Our Price Match Promise
Customer Reviews
Payment Methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
What is the Xpelair XIMX150 for?
It's an in-line mixed-flow duct fan for 150 mm ducting, for extract across domestic and light-commercial ducted applications, including bathrooms (Part F compliant).
How much air and what duct size?
Up to 520 m³/h through 150 mm ducting.
Can it be speed controlled?
It's a two-speed fan, with the speed selected on installation.
Is it maintenance-free?
Yes, a lubricated-for-life motor with thermal cut-out protection, so no routine maintenance is needed.
How is it installed?
It includes a convenient mounting cradle and an easily accessible terminal box, simplifying installation and later inspection; suits inline loft fitting.
Who should install it?
As a mains fan it should be installed on a suitable circuit by a qualified electrician.
