Product Details
Specifications
Product specifications
| Brand | Elta |
| Model | Jetflow Silent SJMF250-S |
| Type | Silent in-line mixed-flow duct fan (EC) |
| Duct connection | 250 mm |
| Airflow (max) | 1591 m³/h |
| Motor | Brushless EC, direct drive (IPX4) |
| Impeller | High-efficiency jet-design double mixed-flow |
| Bearings | Sealed-for-life heavy-duty NWB |
| Max air temperature | +60°C |
| Supplied with | 1.5 m mains lead, UK 3-pin plug (3A fuse) |
| Warranty | 2 Year Manufacturer |
Summary
See more specification See less specification
The Elta Jetflow Silent SJMF 250-S is a high-efficiency EC in-line mixed-flow duct fan. Its jet-design double mixed-flow impeller is integrated and directly driven by a brushless EC motor, delivering up to 1591 m³/h through 250 mm duct with high static pressure. It's acoustically designed for low noise levels.
- Airflow up to 1591 m³/h; 250 mm connection
- Brushless EC motor, direct drive; IPX4
- High-efficiency jet-design double mixed-flow impeller
- Sealed-for-life heavy-duty NWB bearings; suitable up to +60°C
- Acoustically designed for low noise levels
- Fitted with a 1.5 m mains lead and UK 3-pin plug (3A fuse) for easy connection and isolation
Suitable for
- Commercial kitchens, catering, factories, schools, retail and commercial units
- Higher-pressure duct extract where energy efficiency matters
Installation
Fitted with a 1.5 m mains lead and BS1363 UK 3-pin plug (3A fuse), convenient for connecting to a socket and providing a means of isolation/disconnection. Install per the supplied instructions.
Specifications
| Brand | Elta |
| Model | Jetflow Silent SJMF250-S |
| Type | Silent in-line mixed-flow duct fan (EC) |
| Duct connection | 250 mm |
| Airflow (max) | 1591 m³/h |
| Motor | Brushless EC, direct drive (IPX4) |
| Impeller | High-efficiency jet-design double mixed-flow |
| Bearings | Sealed-for-life heavy-duty NWB |
| Max air temperature | +60°C |
| Supplied with | 1.5 m mains lead, UK 3-pin plug (3A fuse) |
| Warranty | 2 Year Manufacturer |
Manuals & Guides
Elta Jetflow Silent SJMF 250-S Datasheet
Elta Jetflow Silent SJMF 250-S Installation Guide
Product Description
The Elta Jetflow Silent SJMF 250-S is a high-efficiency EC in-line mixed-flow duct fan. Its jet-design double mixed-flow impeller is integrated and directly driven by a brushless EC motor, delivering up to 1591 m³/h through 250 mm duct with high static pressure. It's acoustically designed for low noise levels.
- Airflow up to 1591 m³/h; 250 mm connection
- Brushless EC motor, direct drive; IPX4
- High-efficiency jet-design double mixed-flow impeller
- Sealed-for-life heavy-duty NWB bearings; suitable up to +60°C
- Acoustically designed for low noise levels
- Fitted with a 1.5 m mains lead and UK 3-pin plug (3A fuse) for easy connection and isolation
Suitable for
- Commercial kitchens, catering, factories, schools, retail and commercial units
- Higher-pressure duct extract where energy efficiency matters
Installation
Fitted with a 1.5 m mains lead and BS1363 UK 3-pin plug (3A fuse), convenient for connecting to a socket and providing a means of isolation/disconnection. Install per the supplied instructions.
Specifications
| Brand | Elta |
| Model | Jetflow Silent SJMF250-S |
| Type | Silent in-line mixed-flow duct fan (EC) |
| Duct connection | 250 mm |
| Airflow (max) | 1591 m³/h |
| Motor | Brushless EC, direct drive (IPX4) |
| Impeller | High-efficiency jet-design double mixed-flow |
| Bearings | Sealed-for-life heavy-duty NWB |
| Max air temperature | +60°C |
| Supplied with | 1.5 m mains lead, UK 3-pin plug (3A fuse) |
| Warranty | 2 Year Manufacturer |
Manuals & Guides
Elta Jetflow Silent SJMF 250-S Datasheet
Elta Jetflow Silent SJMF 250-S Installation Guide
Delivery & Returns
Our Price Match Promise
Payment Methods
Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.
What is the Elta Jetflow Silent SJMF 250-S for?
It's a high-efficiency EC in-line mixed-flow duct fan for 250 mm ducting, for commercial kitchens, catering, factories, schools, retail and commercial units.
How much air and what duct size?
Up to 1591 m³/h through 250 mm ducting.
Why an EC motor?
The brushless EC motor is highly energy-efficient and easy to control, directly driving a jet-design double mixed-flow impeller for strong airflow and high static pressure.
Is it quiet?
Yes, this Silent (-S) version is acoustically designed for low noise levels while keeping the same performance.
How is it installed?
It's fitted with a 1.5 m mains lead and UK 3-pin plug (3A fuse), convenient for connecting to a socket and providing a means of isolation.
Is it maintenance-free?
Yes, sealed-for-life heavy-duty bearings mean no routine lubrication; install on a suitable supply per the instructions.
