Vent Axia ESC50014 Short Cased Axial Fan Single Phase 500mm
Vent Axia ESC50014 Short Cased Axial Fan Single Phase 500mm
£963.99
SKU: ESC50014

Vent Axia ESC50014 Short Cased Axial Fan Single Phase 500mm

1 Phase
AC Motor
Up to 7560 m³/h
Estimated delivery
In stock
Not sure what you need? Email the teamhello@efans.co.uk
Free 14 day returns

Changed your mind or ordered the wrong unit? You have 14 days from delivery to send it back. As long as items are unused and in their original packaging, we'll arrange your refund. Just contact our team and we'll take care of the rest. Made-to-order and bespoke items are non-returnable.

Why choose eFans?
  • Bulk pricing available
  • Free help and advice
  • Fast quotes, usually within the hour
  • Huge range with next-day delivery
  • Credit accounts available
Delivery and Warranty

Standard UK Mainland Delivery
If you are not in a rush, then we offer standard delivery and your order should be with you between 2-3 working days.
£6.95

Next Working Day Delivery
Place your order before 12pm Monday to Thursday and receive your order the next working day. Orders placed on Friday before 11am will be processed and delivered on Monday. (Excludes Sunday’s and Public Holidays)
£15.95

Nominated Day Delivery
We know sometimes you will need an order on a particular date in the future. Simply select this option at checkout and add what date you would like to receive the order. We will then contact you to confirm the date. If you need to change this order date then please contact us ASAP.
£15.95

Northern Ireland Delivery
We offer a flat fee rate for Northern Ireland orders, and all are 5-7 working day lead times.
£29.95

Scottish Highlands & Islands Delivery
We only offer a flat fee rate for Scottish Highland & Islands orders, and all are 5-7 working day lead times.
£45.95

Channel Islands Delivery
We only offer a flat fee rate for Channel Islands orders, and all are 5-7 working day lead times.
£45.95

Product Details

Specifications

Product specifications
Brand Vent-Axia
Model ESC50014
Type Cased axial fan
Diameter 500mm
Max airflow 7560 m³/h
Phase Single phase
Power 0.51 kW
Voltage 220 to 240V 50Hz
Noise 55 dB(A) at 3m
IP rating IP54

Summary

The Vent-Axia ESC50014 is a 500mm short cased axial fan from the EuroSeries ESC range, delivering airflow up to 7560 m³/h.

This single phase 4 pole AC model with die cast aluminium impeller and external rotor motor suits commercial and industrial supply or extract ventilation. It is fully speed controllable, reversible, and protected to IP54.

See more specification See less specification

The Vent-Axia ESC50014 is a 500mm short cased axial fan from the EuroSeries ESC range, delivering airflow up to 7560 m³/h. It uses a single shot die cast aluminium impeller and an external rotor motor for reliable duct-mounted supply or extract ventilation.

This single phase 4 pole AC model suits commercial and industrial applications where a compact, robust cased fan is needed. It is fully speed controllable, reversible for supply or extract, and protected to IP54 with Class F motor insulation rated from -40°C to +70°C.

  • 1 Phase
  • AC motor
  • Up to 7560 m³/h
  • Speed controllable

Specifications

Brand Vent-Axia
Model ESC50014
Type Cased axial fan
Diameter 500mm
Max airflow 7560 m³/h
Phase Single phase
Power 0.51 kW
Voltage 220 to 240V 50Hz
Noise 55 dB(A) at 3m
IP rating IP54

Manuals & Guides

Vent-Axia EuroSeries ESC Short Cased Axial Fan Datasheet

Product Description

The Vent-Axia ESC50014 is a 500mm short cased axial fan from the EuroSeries ESC range, delivering airflow up to 7560 m³/h. It uses a single shot die cast aluminium impeller and an external rotor motor for reliable duct-mounted supply or extract ventilation.

This single phase 4 pole AC model suits commercial and industrial applications where a compact, robust cased fan is needed. It is fully speed controllable, reversible for supply or extract, and protected to IP54 with Class F motor insulation rated from -40°C to +70°C.

  • 1 Phase
  • AC motor
  • Up to 7560 m³/h
  • Speed controllable

Specifications

Brand Vent-Axia
Model ESC50014
Type Cased axial fan
Diameter 500mm
Max airflow 7560 m³/h
Phase Single phase
Power 0.51 kW
Voltage 220 to 240V 50Hz
Noise 55 dB(A) at 3m
IP rating IP54

Manuals & Guides

Vent-Axia EuroSeries ESC Short Cased Axial Fan Datasheet

Delivery & Returns

Our Price Match Promise

Payment Methods

American Express Apple Pay Diners Club Discover Google Pay Maestro Mastercard PayPal Shop Pay Union Pay Visa

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

What size is the Vent-Axia ESC50014?

It is a 500mm cased axial fan.

What airflow does the ESC50014 deliver?

Up to 7,560 m³/h at free air.

Is the ESC50014 single or three phase?

It is a single phase 4 pole AC fan running on 220 to 240V.

Can the ESC50014 be speed controlled?

Yes, it is fully speed controllable, ideally with an auto transformer controller for low noise.

Can the ESC50014 be used for supply and extract?

Yes, the fan is reversible for supply or extract duties.

What is the IP rating of the ESC50014?

The motor is protected to IP54.
